Description
Compact Incubator Temperature Range ambient +5 °C to +50 °C Model: JSGI-10T JSR Korea
10 Liter, 30 Liter small volume incubator, Temperature Range ambient +5 °C to +50 °C.
| Download Data Sheet | JSGI-10T |
| Compact Incubator | 10 Liter |
General Specifications
| Heating | JSGI-10T : Gravity Convection |
| JSGI-30T : Forced Air Convection | |
| Temp. Range | ambient + 5 oC ~ 50 oC |
| Accuracy | ± 1.0 oC at 37.0 oC |
| Uniformity | ± 2.0 oC at 37.0 oC |
| Control | Microprocessor PID Control Auto START / STOP Timer |
| Sensor | Class A Pt-100 Ω Sensor |
| Safety | Over-Temperature Cut-Off |
| Over Current Cut-Off | |
| Material | Body – Epoxy Powder Coated Steel |
| Chamber – Stainless Steel 304 | |
| JSGI-10T without Inner Glass Door | |
| JSGI-30T with Tempered Safety Inner Glass Door | |
| Shelf -including PVC coated wire shelf | |
| Electric | 220±10% VAC 50/60Hz 1-Phase |
| Plug config. | CEE 7/7 Schuko or BS 1363 |
Features
| Controller |
| • ±0.1 oC Digital PID Controller with LED Display
• Automatic START/STOP timer • Adjustable timer scale 99min 59sec / 99hr 59min / 99day 23hr or continuous operation • Temperature calibration • Auto-tuning function • Class A Pt-100 Ω sensor
|
| Construction |
| • Durable epoxy powder coated metallic casing
• Corrosion resistant Stainless Steel 304 chamber • Inner glass door (JSGI-30T)
|
| Performance |
| • Mild gravity convection with durable silicone film heater (JSGI-10T)
• Forced air convection with separate heating compartment (JSGI-30T) • Simple and durable design permits practical usage of bacteria screening such as HACCP laboratory
|
| Convenience |
| • Outer door with self adhesive magnetic packing
• 2 tier removable shelf
|
| Safety |
| • Controller cut-off heater and ALARM in case +2 oC above set temperature
• Controller cut-off heater and ALARM in case +1 oC above maximum temperature limit • Over-Temp. Safety Cut-Off • SENSOR DISCONNECTION ALARM • OVER CURRENT CUT-OFF : Fuse |
Model
| DESCRIPTIONS | JSGI-10T |
| Dimension Data | |
| Chamber Volume | 9.3 Liters |
| Inner Dims. (W x D x H mm) | 210 x 210 x 210 |
| Outer Dims. (W x D x H mm) | 315 x 370 x 435 |
| No. of Wire Coated Shelf included | 2 ea |
| No. of Shelf Position | 2 ea x 72mm spacing |
| Inner Glass Door | No |
| Performance Data | |
| Heating System | Gravity Convection |
| Temp. Range | Amb. +5 oC ~ +50 oC |
| Accuracy | ±1.0 oC at 37 oC |
| Uniformity | ±2.0 oC at 37 oC |
| Electrical Data | |
| Rated voltage | 220 ± 10% VAC |
| Power frequency | 50 / 60Hz |
| Heater Output | 60 W |
| Nominal power | 60 W 0.3 amp |
| Phase | 1 Phase |
| Plug configuration | CEE 7/7 Schuko |
Ordering Information
| Art No. | Descriptions | Capacity | Elec. Req. |
| JSGI-10T | Compact Incubator | 10 L | 220 VAC 50/60 Hz |
Optional Accessories
| Art No. | Descriptions |
| PHS-C01 | Wire Coated Shelf, W205 x D200 mm for JSGI-10T |
| PHS-C02 | Wire Coated Shelf, W295 x D290 mm for JSGI-30T |
| PHS-A99 | Shelf Support, Set of 4 for JSGI-30T |
