Autoclave/Steam Sterilizer 85 L Model JSAT-85T JSR Korea
MAIN FEATURES
PERFORMANCE
-Maximum sterilization temperature and pressure up to 123 oC and 0.13 Mpa
-Automatic sterilization cycle starts just by setting sterilization temperature and time
-Validation compliance performance with accuracy within ± 0.5 oC and uniformity within + 2.0 oC above 121 oC
CONTROLLER
-JSC-2D Digital PID Controller with ±0.1 oC resolution
-Automatic START/STOP timer
-Dual LED displays temperature and remaining time
-Temperature calibration function and Auto-tuning function
-Class A Pt-100 Ω sensor
CONSTRUCTION
-Vertical loading type chamber with 2 ea service baskets
-Light-weight lifting door
-SAFETY DOOR INTER-LOCKING SYSTEM lock the door during operation which integrated with temperature, pressure in the chamber and in case electric cut-off
-Stainless steel 304 (AISI 304) chamber, lid and top plate to protect from corrosion by water and steam
-Special plated heating element provides resistant to corrosion and guarantee long life in repeated use
-Two Stainless Steel Wire Basket included
CONVENIENCE
-Two steam collection bottles removes most of steam generated during operation for comfortable laboratory environment
-Equipped with drain valve for cleaning and changing with fresh water
-High pressure and temperature resistant silicone gasket
-Built-in analog pressure gauge
-Manual pressure release valve
-Caster for easy transport
SAFETY
-SAFETY DOOR LOCK with Door interlocking system integrated with high temperature, pressure and electric cut-off
-TRIPLE OVER-TEMP. CUT-OFF
-Controller cut-off heater and AUDIO VISUAL ALARMS in case +2 oC above set temperature
-MAX TEMP CUT-OFF heater and AUDIO VISUAL ALARM when +0.1 oC above 125 oC
-TRIPLE OVER-PRESSURE CUT-OFF
-Controller open valve to release excess pressure and AUDIO VISUAL ALARM in case +2℃ above set temperature
-Controller open valve to release excess pressure and AUDIO VISUAL ALARM in case +0.1℃ above +125℃
-Mechanical over pressure valve automatically release excess pressure in case over maximum pressure limit 0.15 Mpa
-ANALOG PRESSURE GAUGE
-Analog system cut-off heater 10% above set temp.
-0 ~ 0.3 Mpa pressure gauge indicating actual pressure
-MANUAL PRESSURE RELEASE VALVE for emergency
-OVER CURRENT CUT-OFF : Electrical Leakage Breaker
SPECIFICATIONS
| MODEL | JSAT-85T |
| Capacity and Dimensions | |
| Capacity | 85 Liters |
| Inner Dims. (Dia. x H) mm | f450 x H535 |
| Outer Dims. (W x D x H) mm | 610 x 780 x 1010 |
| Usable Dims. (Dia. x H) mm | f450 x H480 |
| Basket Dims. (Dia. x H) mm | f430 x H220 |
| Basket | Electro-polished Stainless Steel 304 wire basket |
| No. of basket included | 2 EA |
| Performance Data | |
| Temperature Range | up to +123 oC |
| Accuracy | ±0.5 oC at 121 oC |
| Uniformity | within +2.0 oC above 121 oC |
| Operating Pressure Range | up to 0.12 MPa |
| Pressure Gauge Range | 0 ~ 0.3 MPa |
| Controller | |
| Type | Microprocessor PID control |
| Auto START / STOP Timer | |
| Sensor | Class A PT-100 Ω Sensor |
| Timer | 99min 59sec by 1 sec division |
| Display | PV and SV or Timer Dual Display |
| Independent ON/OFF Switch | |
| Printer | Thermal Printer [OPTION] |
| Safety Data | |
| Safety Device | Safety door lock |
| Triple over temp. cut off | |
| Triple over pressure cute off | |
| Analog pressure gauge | |
| Manual pressure release valve for emergency | |
| Over current cut-off : Electrical Leakage Breaker |
| Material Data | |
| Body | Epoxy Powder Coated Steel, 1.0 mm thickness |
| Chamber, Lid, Top Plate | Stainless Steel 304 |
| Gasket | High Density One-piece Silicone |
| Electrical Data | |
| Rated voltage [VAC] | 220 ± 10% |
| Power frequency [Hz] | 50/60 |
| Nominal power [kW] | 3.0 |
| Power Rating [Amp] | 13.6 |
| Phase (Nominal voltage) | 1~ |
| Plug configuration | CEE 7/7 Schuko or BS 1363 |
| Usable Condition | |
| Temp. & Humidity | 5oC – 40 oC, < 80% RH |
| Altitude | Less than 1,000 m above sea level |
| Standard Accessories included | |
| Heater Cover | 1 |
| Stainless Steel Wire Basket | 2 |
| Steam Collection Bottle | 1 |
| Operation Manual | 1 |
| Warranty Certificate | 1 |
| Packaging Data | |
| Shipping Dims. (W x D x H mm ) | 850 x 750 x 1180 |
| Type of packaging | Carton on a wooden palette |
| Net Weight (kg) | 113.0 |
| Shipping Weight (kg) | 130.0 |
ORDERING INFORMATION
| Art. No. | Descriptions | Voltage |
| JSAT-85 | Autoclave, 85 Liters | 220 VAC 1~ ph 50/60Hz |
| including standard accessories | ||
| 1 ea x Heater Cover | ||
| 2 ea x Stainless Steel Wire Basket | ||
| 2 ea x Steam Collection Bottle | ||
| 1 ea x Operation Manual | ||
| 1 ea x Warranty Card |
OPTIONAL ACCESSORY
| Art. No. | Descriptions |
| OER-020 | Thermal Printer, Time/Date/Temp. Recording [Factory built-in] |
SPARE ACCESSORIES
| Art. No. | Descriptions |
|
PHG-A06 |
Stainless Steel 304 Wire Basket for JSAT-85, ø450 mm |
|
PHC-A02 |
Heater Cover for JSAT-85 |
|
PHG-A06 |
Silicone Gasket for JSAT-85 |
| PHB-A06 | Steam Collection Bottle for JSAT-85 |
