Description
Vertical Autoclave LVA-D11 Labtron
Description
Vertical Autoclave LVA-D11 is a class N-type top-loading vertical pressure steam sterilizer, with hand wheel type, quick to open door structure. It offers a chamber capacity of 50 L, working sterilization temperature and pressure of 134°C and 0.22 MPa respectively. Designed with four wheels (castors) at the base for easy movement of the unit. The standard 02 pcs of stainless steel baskets to keep the sterilization material load. The 304-grade stainless steel with superior corrosion resistance property is used as a construction material for the autoclave. It works on electric heating or direct heating by immersing copper tubes of heating elements. It is possible to customize autoclave with an optional drying system, according to the request.
Specification
| Capacity | 50 L |
| Chamber Volume | 340×550 mm |
| Working Sterilization Temperature | 134°C |
| Working Sterilization Pressure | 0.22 MPa |
| Time Range | 0 to 99 mins |
| Maximum Working Pressure | 0.23 MPa |
| Sterilization Temperature Range | 105 to 134°C |
| Heat Average | ≤ ± 1°C |
| Power Consumption | 3 kW |
| Power supply | AC 220 V, 50 Hz |
| Overall Dimension | 510×470×1130 mm |
| Packing Dimension | 590×590×1280 mm |
| Net weight | 68 kg |
| Gross weight | 88 kg |
