Description
Digital Overhead Stirrer Model: JSMS-150D JSR Korea
JSMS-xxxD Digital Overhead Stirrer designed to homogenization, emulsification and dispersion and mixing of fluids at high speed. This compact and rugged Overhead Stirrer is user-friendly designed with convenient Jog-Dial and High Fidelity LCD Display. Advanced Fuzzy Control System maintaining accurate and consistent RPM and equipped with heat protection safety cut-off system. Gearless torque conversion mechanism ensure less heat generation and anti-trembling shaft guarantee vibration and noise free operation.
SELECTION GUIDE
| Model No. | VISCOSITY | TORQUE | SPEED | |||
| JSMS-150D | HIGH | ~ 100,000 Mpas | HIGH | ~ 300Ncm | Low | 80~1200 rpm |
Specifications
| Art No. | JSMS-150D |
| Stirring Capacity H2O | 60 liter |
| Max. Viscosity | 150,000 mPas |
| Max. Torque | 450 Ncm |
| Speed Range | 50 ~ 800 rpm |
| Speed Control Resolution | 1 rpm |
| Gear Rate | 4.5 : 1 |
| Power Consumption | 200 Watt |
| Motor Rating (input/output) | 110 / 85 Watt |
| Timer | 1 min to 99 hr 59 min |
| Control | Digital Fuzzy Control with Capacitive Touch Button and Jog Dial |
| Full Size Digital Back Light LCD Display | |
| Independent ON/OFF Switch | |
| Max. Impeller Diameter | Φ 10 mm |
| Motor | Brushless Shade Motor |
| Safety | Over Load Protection |
| Over Heat Protection | |
| Material | Aluminum casting with epoxy powder coating, ABS Plastic |
| Power Rating | 650 watt, 3.0 amps |
| Electrical Requirement | 230 ± 10% VAC, 50/60Hz, 1-Phase |
| Power Plug | CEE 7/7 Schuko European Standard |
Features
| Controller |
| Advanced microprocessor Digital Fuzzy Controller with Touch button and Jog Dial.
Accurate stirring speed control and display Rugged, solid and chemical-proof control panel surface Touch-sensitive Multi-Functional Capacitive Button compatible to all kind of latex gloves as well as finger touch. Easy-to-use Jog Dial for quick and convenient setting of stirring speed. Push to Run, Stop and Save value. High-fidelity clear back light LCD displays complete setting and operating condition at a glance. Easy to monitoring set rpm, present rpm and time. |
| Construction |
| Compact and handy design to fit all purpose.
Main body made by aluminum casting with durable ABS Plastic.
|
| Performance |
| Stirring Capacity 25 to 60 liter H2O depends on model.
Viscosity 70,000 ~ 150,000 mPas depends on model. Speed Range 800 to 2,000 rpm depends on model. Timer setting range from 1 min to 99 hr 59 min Anti-trembling shaft ensure high speed stirring, vibration and noise free operation. Stainless Steel anti-rust thread chuck |
| Safety |
| OVER LOAD and OVER HEAT PROTECTION |
Ordering Information
| Art No. | Descriptions | Viscosity | Torque | RPM | Elec. Req. |
| JSMS-150D | Digital Overhead Stirrer | 100,000 mPas | 300 Ncm | 80~1200 rpm | 230 VAC 50/60 Hz |
