Description
Clamp Meter CM-6158 Lutron Made in Taiwan
CM 6158 Clamp Meter is a Smart function, Auto range or manual range withhold and Smart operation, Built-in 4 intelligent functions: “V”, “Ω”,”600A”, and “1000A” That is rugged.
Lutron CM-6158 Clamp-On “Smart” Amp Meter 2000 Amp AC or DC – “Smart” measurements automatically detect AC or DC Values when measuring Current or Voltage!
Features:
- Meet IEC 1010 CAT III 1000 V safety requirement.
- 6000 counts A/D, high resolution.
- ACV, ACA, DCV, DCA, ohms, continuity, Hz, Capacitance, Diode.
- Smart function, Auto range or manual range with hold.
- Smart operation, Build in 4 intelligent function : ” V “, ” Ω “,” 600A “, ” 2000A “.
- ” V ” function can select ACV, DCV automatically with auto range.
- ” Ω ” function can select the Resistance , Diode, Continuity beeper, Capacitance automatically with auto range.
- ” 600A ” & ” 2000A ” function can select ACA, DCA automatically.
- Data hold
- Auto shut off is available to save battery life.
- 10 M ohm impedance for voltage circuit.
- Built-in overload protection for most ranges.
- LSI circuit provides high reliability and durability.
- Uses durable, long-lasting components, enclosed in strong, light weight ABS-plastic housing.
Specification:
Display :39.5 mm x29.8 mm large LCD display
Measurement: DCV, ACV, DCA, ACA, Resistance, Capacitance, Frequency, Diode, Continuity beeper.
A/D counts no. :6000 counts.
Smart function: “V” function can select ACV, DCV automatically with auto range.
“Ω” function can select the Resistance, Diode, Continuity beeper, Capacitance automatically with auto range.
600A ” ” 1000A ” function can measure ACA, DCA.
Data hold: To freeze the display reading on the LCD display
Power On/Off management: Auto power of or manual power off.
Hz button: When executing the voltage or current function also can measure the frequency of the signal.
Selection Range: Smart function or auto function. manual range selecting.
Polarity: Automatic Switching, ” – ” indicates negative polarity.
Sampling time: Approx. 0.5 to 1 second.
Operating Temp :0 to 50 (32 to 122 )
Operating Humidity :Max. 80% R.H..
Power supply: DC 9 V battery 006P, MN1604
Power consumption: Approx. DC 9.1 mA
Max. Size Conductor :48 mm (1.89 inch) Dia.
Dimension :253 x94 x 46 mm ( 9.96 x 3.7 x 1.8 inch ).
Weight :440 g/0.97 LB ( w/o battery ).
Accessories Included: Red and Black Test Leads 1 Set, Instruction Manual, Soft carrying case
Optional Accessories: Full line adapters: ACA/DCA current adapter, Tachometer adapter, Humidity adapter, Pressure adapter, Light adapter, EMF adapter, Sound level adapter, High voltage probe.
